DMS-GA2-V
Infrared, half duplex 4 bit, NPN, head on device, 3m range.
Overview
These devices provide infrared half duplex, 2 way 4 bit data transmission (head on) packets across 1m or 3m. There are NPN and PNP options available.
Operation Benefits
Indoor/ Outdoor – Indoor
Range – 3m
Head On/Side On – Head On
Communication – Infrared half duplex 2 way data transmission
Weight – 280g
Technical Information
Technology – Infrared Data Transmission
Range – 3m
Reviews (0)
Product Details
- Technology - Data Transmission
- Range - 3m
- Direction - Head On
- Directional Angle (full angle) - 10º
- Model Type - 4 bit
- Transmission method - Half duplex, two way transmission
- Transmission time - 40ms or less
- Modulation Method - Pulse modulation
- Detection Method - Parity Check
- Projecting Element - Near infrared LED
- Receiving Element - Photo-transistor
- Power Source - 10 to 30VDC
- Current Consumption - 100mA or less
- Input - Contact or Contactless open collector (ON current 2.5mA or more, OFF current 1mA or less)
- Output - NPN Open Collector (30V, 50mA or less)
- Connection - 2m cable, 15 cores, shielded
- Ambient Illuminance - 4,000lux or less (incandescent light)
- Ambient Temperature/humidity - -10 to +50 C 85% RH or less (Without dew, frost)
- Vibration Resistance - Double amplitude 1.5mm, 10 to 55Hz, each 2 hour in X, Y & Z directions
- Impact Resistance - 501 m/s2, each 10 time in X, Y & Z directions
- Protective Structure - IP64 (IEC standards)
- Case Material - Polycarbonate
- Weight - Approx. 280g (excluding cable)
Resources & Information
Additional information
Additional information
| Manufacturer | Hokuyo |
|---|
